ACME XP500 BEAM 420W Sharp Beam Light Multi Prism Static Gobo DMX Moving Head Stage Light

Brand Name:	ACME
Model Number:	XP500 BEAM
MOQ:	2
Price:	$450-$480
Payment Terms:	L/C,D/A,T/T,D/P,Western Union
Supply Ability:	300

Detail Information

Product Description

Detail Information

Place of Origin:

China

Display And Interfaces :

LCD Screen, 3-pin/5-pin DMX Interface, Power Socket

Category:

Wattage Of The Light Source:

Accessories:

Light Hooks, Safety Ropes, Power Cords, Signal Cables

Condition Percentage :

OLike New (99% New)

Spot Inventory:

Years:

Packaging Details:

Flying box

Supply Ability:

Highlight:

420W sharp beam stage light

DMX moving head stage light

static gobo prism stage light

Product Description

The XP500 BEAM model ARES, an ACME flagship high-power pure beam moving light, is mainly used for long-distance sharp light beams, multi-layer prism effects, and a wide range of pattern colors. It is the main light beam equipment for indoor tours, music festivals, electronic music events, large-scale performances, bars, and stadiums.

II. Light Source and Core Optical Parameters (Indoor Standard Version)

Light Source: MSD Platinum 19R LL 420W Gas Discharge Lamp
Reference Color Temperature: 6700K, Rated Lifespan 5000 Hours
Total Light Output: 9900lm, Total Power Consumption 570W, Voltage 100–240V 50/60Hz
Super Large Optical Lens: 200mm Large Aperture High-Definition Coated Lens
Minimum Beam Angle: Only 1.3°, The Light Beam is Extremely Fine and Has Strong Penetrating Power
10-meter Illumination: Up to 990,000lux, No Decay at Long Distances in the Venue
Electrically Precise Focusing: Throughout the Process No Fuzzy Edges, No Spotted Light Flashes, Sharp and Clean Edge of the Light Beam

III. Color System (Multi-layer Color Combination, Rainbow Dynamic)

Linear CMY Infinite Mixing Color: Red/Green/Blue independent gradient, Smooth Color Transition without Breaks
Independent Color Discs: 12 Saturated Color Plates + White Light, Built-in Red Reduction Filter, High CRI Correction Plate, Balancing Atmosphere Light and Portrait Supplementary Color
Bidirectional High-Speed Rainbow Rolling Effect: Speed Adjustable; Combined with CTO Linear Color Temperature Correction 3200K–6500K, Continuous Switching from Cold White Light to Warm Yellow Light

IV. Patterns and Special Effects Wheel (Warrior of Patterns, Multi-layer Superposition)

1. Fixed Pattern Disk
- 10 High-Definition Metal Color Separation Patterns + 3 Flowing Special Effects Patterns + White Circle, Clear Patterns with Sharp Edges
2. Independent FX Effect Wheel (Double-layer Function)
- First Layer: 3 Water Wave / Cloudy Dynamic Plates, Can Overlap and Superimpose with the Fixed Pattern
- Second Layer: Light and Heavy Two Layers of Uniform Soft Light Plates, Eliminate Center Hole of the Light Beam, Balance Sharp Light Beam and Soft Light Spots
3. Multi Prism Combination (Core Selling Point, 8 Different Superposition Methods)
- Four Independent Prisms, All Support Bidirectional 360° Rotation, Arbitrary Superposition Activation:
- 8-Sided Octagonal Prism, 24-Sided Polyhedral Prism, 48-Sided Fine Prism, 6-Sided Linear Prism
- Single Prism, Double Prism Combination Can Produce Several Decades of Three-Dimensional Multi-Layer Light Beams, Electronic Music, High-Power Stage Atmosphere Fully Enhanced
4. Independent Fuzzing Plate
- Separate Soft Light Filter, One-click Switch Between Sharp Light Beam / Large Area Softening Light Spot, Balancing Light Beam and Light Coloring Dual Modes

V. Dimming, Strobe, and Three-Axis Head Movement

Dimming System: 0–100% Electronic Linear Smooth Dimming,
High-Speed Strobe: 0–30 Times/Second Variable Burst Flash, Synchronous / Asynchronous Strobe, Pulse Flash, Suitable for Nightclubs, Rock Stage
High Precision 16-bit Positioning Motor: No Jitter in Movement, Automatic Out-of-Band Correction
Horizontal Pan: 540° Wide Range Scanning
Vertical Tilt: 260° Pitch
Support Horizontal / Vertical Axis Locking: Fixed Light Beam at Point, High-Speed Movement No Trail

VI. Signal Control and Body Operation

Standard DMX512: 3-pin + 5-pin XLR Input/Output, Dual Channel Mode 17/21 Channels
RDM Remote Device Management: Remote Address Reading, Fault Detection, Parameter Modification
Body Backlight LCD Display: Power Off Memory Address Codes and Parameters
Firmware Upgrade: Support Local USB Upgrade, DMX Line Online Upgrade
Power Direct Output: Multiple Lamps Connected in Series Wiring, Simplifies Stage Wiring

VII. Physical Structure and Installation (Indoor IP20 Version)

Overall Size: 350×223×668mm
Net Weight: 28kg, Lightweight Tour Body, Reduces Truss Bearing Pressure
Standard 2 50mm Foldable Omega Lamp Hooks: Support Standing / Inverted Installation Methods
The air duct circulation cooling system ensures stable temperature control even during long periods of full-power operation, with low noise levels.
