1400W ACME AECO20 LED Profile Light 4 Independent Cutting Blades CMY Mix Zoom Stage Moving Head Light

II. Core Light Source and Optical Parameters

III. Color System (Seamless Mixing, Rich Colors)

AECO20 Function Icon Overview

• Linear CMY Infinite Color Mixing: Independent linear gradient of red/green/blue colors, smooth color transition without any breaks, supports any saturation overlay
• Double-layer Fixed Color Wheel (total 11 colors + white light)
  • Color Wheel A: 6 colors of color + white
  • Color Wheel B: 5 colors of color + white, includes UV filter, supports bidirectional rainbow dynamic effect
• Linear CTO Color Temperature Correction: Continuous adjustable from cold white 6000K to warm yellow 2700K, suitable for character frontal light, atmosphere warm light scenes

Four, Pattern and Dynamic Effect System

• Fixed Pattern Wheel: 9 high-definition color-separated glass patterns + white circle
• Rotating Pattern Wheel: 7 high-precision patterns that can rotate in both directions + white circle, sharp edges without blurring
• Replaceable Dynamic Effect Wheel: Flowing light effects such as water waves, flames, and clouds, supports 360° bidirectional rotation, can quickly change effect sheets
• Prism Combination (can be stacked, bidirectional rotation)
  • 4-sided octagonal prism
  • 4-sided straight-line linear prism

  When both prisms are turned on, it can create multi-layer divergent light beams, suitable for climax atmosphere lighting

• Two high-brightness fogging sheets (light / medium soft light)

  New high-transparency soft light material, after fogging, the brightness reduction is reduced, can be used separately / stacked; quick switch between sharp light beams and soft colored light spots

Five, Core Patents 4-Leaf Cutting System (Product Core Selling Point)

• 4 independent electric cutting blades, each blade can be adjusted separately for angle, opening, and rotation, cutting edges are clean and neat, without stray edges or shadows
• The entire cutting module supports overall ±60° rotation, can arbitrarily cut square, trapezoid, polygon, and irregular-shaped light spots
• Smooth operation, quiet, fast image cutting, person cutting, stage area cutting, essential for precise composition in theaters and press conferences
• Built-in mechanical linear diaphragm: 0–100% continuous light reduction, shrinking the size of the light spot, shaping hard-cut outlines

Six, Dimming, Strobe, and Head Movement

• Dimming: 0–100% electronic linear smooth dimming, 4 dimming curves can be selected, no strobe, no brightness discontinuity
• Strobe: Multiple adjustable speed strobe, synchronous / asynchronous burst flash, suitable for rock, electronic music stages
• Three-axis head movement (16-bit high-precision positioning, no jitter)
  • Horizontal Pan: 540°
  • Vertical Tilt: 270°

  Supports horizontal / vertical movement locking, fixed light spot at a specific point

  Precise positioning back to the center, fast movement without ghosting, suitable for rapid switching of compositions in large-scale performances
