470W 18R Used Stage Lights BSW 3 In 1 Moving Head Light SKYF500BSW DMX512

Brand Name:	SKY
Model Number:	F500
MOQ:	2
Price:	$35-$50
Payment Terms:	L/C,D/A,D/P,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Name:

Used Stage Lights

Category:

Wattage Of The Light Source:

Accessories:

Light Hooks, Safety Ropes, Power Cords, Signal Cables

Packaging Details:

flying box

Highlight:

470W Used Stage Lights

18R Used Stage Lights

3 In 1 Moving Head Light

Product Description

SKYF500BSW 470W 18R BSW 3 In 1 Moving Head Light Zoom Beam Spot Wash Stage Light DMX512 Professional DJ Club Concert Wedding Event Stage Lighting Fixture

I. Basic Parameters

Model: F500BSW (SKYF500BSW)

Light Source: Osram/Shenglong NSL-470W Platinum Bulb (18R)

Color Temperature: 7800K, Color Rendering Index (CRI) ≥ 91.3

Luminous Flux: ≥ 20000lm, Illuminance at 10m: Approximately 420,000 lux

Lifespan: 1500 hours (up to 6000 hours in energy-saving mode)

Input Voltage: 100–240V AC, 50/60Hz

Power: 700W (PF=0.985)

Protection Rating: IP20 (Indoor)

Net Weight/Gross Weight: Approximately 22kg/25kg

Dimensions: 410*370*650mm

II. Optics and Effects System

Zoom and Light Output

Large-diameter 160mm optical lens
Beam Patterns: 2°–21°; Pattern Patterns: 3°–42°; Tint Patterns: 1°–5°
Dual focus adjustment + autofocus, uniform bokeh without black edges

Color System

11 color palettes + 2 CTO + white light, bidirectional rainbow, halftone effects
Linear CMY color mixing, wide color gamut, vibrant colors

Pattern System

Fixed Pattern Pad: 10 patterns + white light + flowing animation effects
Rotating Pattern Pad: 7 interchangeable glass patterns, rotation/shaking/indexing
Dynamic Effects Pad: Water ripples, flames, and other effects

Prisms and Fog

Standard configuration: 3+1 dual prisms (8 prisms + 16 prisms), bidirectional variable speed rotation, stackable
Secondary Fog: Light fog 1°, heavy fog 5°, uniformly softened light spot

Dimming / Strobe / Aperture

0–100% flicker-free linear dimming
High-speed strobe: 0.3–25 times/second, pulse/random/synchronous
Motorized aperture: 5%–100%, variable pulse and random effects

III. Scanning and Control

Scanning angle: Horizontal 540°, Vertical 250° (16-bit precision, electronic error correction)
Motors: 23 ultra-quiet motors, three-phase drive
Control channels: 21CH (simplified)/27CH (standard)/32CH (extended)
Control modes: DMX512, RDM, master-slave, auto-run, voice control
Display: LCD backlit screen, 180° invertable, USB software upgrade

IV. Core Advantages

Hotspot elimination: Built-in hot-spot protection to prevent objects from being burned by high temperatures
Ultra-quiet operation: 23 silent motors, suitable for theaters/ Studio Lighting
High CRI: CRI≥91.3, accurate color reproduction
High-power long-range projection: 470W, sufficient brightness, 420,000 lux illuminance at 10m, covering large venues

V. Typical Applications

Large-scale concerts, stadium tours, theater performances
High-end bars/clubs/electronic music festivals (all-around beam + pattern + color-changing)
Weddings, press conferences, auto shows, cultural tourism real-scene lighting
